DESCRIPTION

Basic Info

Model NO.	LT-2030
Certification	ISO, CE
CNC or Not	CNC
Voltage	220V
Model	Lt-1325
Working Area	1300(X)*2500(Y)*200(Z)mm
Machine Structure	Cast Iron Vertical Shafts and Steel Gantry
Table Surface	Aluminum T-Slot Table with PVC/Vacuum Table
Spindle	Water Cooling Spindle/Air Cooling Spindle
Spindle Rotating Speed	0-24000rpm/Min
Guide Rail	Hiwin Linear Square Guide Rail
Power	3.0kw/4.5kw/5.5kw
Driving Method	X, Y by Helicia Gear Rack ;Z by Ball Screw
Motors	Servo/Stepper Motor
Drivers	Leadshine Drivers Ma860h
Control System	Ncstudio/Mach3/DSP Contro System
Invert	Fuling Invert
Standard Software	Artcam2010
Optional	Rotary Axis
Transport Package	One Plywood Case
Specification	3300*1950*1950mm
Trademark	LINTIANZHIYUAN
Origin	China
HS Code	8465990000
Production Capacity	400

Product Description

2021 Hot Woodworking Machinery Cnc Wood Router 3D Carving Machine 1325 2030 2000*3000mm Working Area with Dust Collector

Product Description

Product Parameters

1. Z axis feeding height 200mm

2. Square tube welded steel frame structure-8mm thickness

3. Aluminum T-slot table with PVC/Vacuum table

4. X axis rack and pinion drive, Y axis 2 way rack and pinion drive and Z axis 2510 Ball screw

5. X, Y, Z axis Taiwan square rails PMI

6. 450B stepper motor and MA860H Leadshine driver or servo motor and driver

7. 3.0KW water cooling spindle and 3.7kw Fuling inverter, other spindles are optional

8. Nc-Studio-5.4.49 control system, DSP or Mach 3 is optional

Model			LT-2030 wood cnc router
Working area			2000*3000*200mm
Spindle motor power			3.0KW
Table style			Aluminum T-slot table with PVC
Motor and driver			450B stepper motor and MA860H Leadshine driver/servo
Control system			NCSTUDIO5.4.49/DSP/Mach3
Guide rail			Hiwin linear square guide rail
Transmission			X,Y axis gear rack, Z axis ball screw
Invert			Fuling
Working speed			12m/min
Spindle speed			24000RPM
Traveling speed			25m/min
Processing accuracy			+/-0.025mm
Reposition accuracy			<0.025mm
Command language			G code, HPGL
Working voltage			AC380V, 50Hz
Net weight/ Gross weight			1300KG/1500KG
Package dimension			3200*2040*1900mm
Optional			1. Vacuum absorption table and 5.5KW vacuum pump
			2. Dust collector
			3. Water sink
			4. 4.5KW,5.5KW spindle
			5.Independent head
			6. PMI25 square rail

Samples

Wood Processing: processing of various furniture such as door, window, cabinet, screen and so onAdvertisement: engraving and cutting various labels and number plate. Art crafts: engraving characters of any languages and graphics on gifts and souvenirs.Applicable materialswood, aluminum bord, brass board, plastic, density board, MDF board, wave board, PVC, acrylic, crystal, light marble and other nonmetal materials and light metal materials.

Packaging & Shipping

After Sales Service

1.Technical supports and suggestions before you order a machine according to your work piece. 2. Professional instruction for the operation of the machine.3. 24months warranty, we will provide the consumable parts at cost price after the warranty period. 4. Our technician will come to your workshop if the problems can not be fixed through Internet or phone communications. 5. 24-hour technical support by email or calling.

FAQ

1) This is the first time I use this kind of machine, is it easy operate?

There are nglish manual or guide video that show how to use machine.

If there is still have any question, we can talk from phone or kype.

2)Can you recommend a CNC ROUTER MACHINE to me,thanks?

Yes, In order to give you a suitable router machine, ls tell me the max working

area, materialsfor processing and the thickness for materials processing engraving

or cutting. Then perfect suitable router will be recommended

3) If machine have any problem after I ordered it, how could I do?

Free parts send to you in machine warranty period if machine have any problem.

Free after-sales service life for machine, please feel free contact us if your machine

have any problem.we will give you 24hours service from phone and kype.

4) MOQ ?

Our MOQ is 1 set machine. We could send machine to your country port directly,

please tell us your port name. There will be best shipping freight and machine price

send to you

5)Payment terms

a. 30% by T/T in advance,70% by T/T before shipping.

b. L/C is acceptable ,if the amount is big,please issue the draft for our confirmation at first.

6)Delivery terms We will arrange the delivery as the terms we both agreed with after the confirmation by the buyer.

Company Informati

Shandong Lintianzhiyuan CNC Equipment is located in Jinan, China. Our company focuses on research, production and sale, maintenance service. We depend on high technology and high quality product to build the world brand.Our main product includes Advertising CNC Router, Stone CNC Router, Woodworking CNC Router, Jade CNC Router, Plasma cutting machine, Laser engraving machine, Laser cutting machine and Laser marking machine.
