DESCRIPTION

Basic Info

Model NO.	UG-1630V
After-sales Service	24 Hours Online Service
Waterproof Rating	IPX-0
Warranty	1-year
Certification	CE, ISO 9001:2000
Condition	New
Control	Automatic
Application	Paper, Plastic, Leather, Fabric, Foam, Sponge, Kt Board, PU, EVA, Rubber, XPE
Power Source	Electric
Layout	Horizontal
Working Area	1600*3000mm( X/Y)
Working Table	Fixed Aluminum Adsorption Vacuum Working Table
Guide Rail	Linear Square Guide Rail ( Original PMI, Taiwan)
Transmission	Helical Rack &Pinion for X Y -Axis, Wmh Brand, Her
Driving Mode	Servo Motor and Drivers, Yaskawa, Japan
Cutting Head	4 Sets
Oscillating Knife	High 400W
Milling Cutter	3.5kw Air Cooling
Creasing Wheels	with
Mark Pen	with
Control System	Ruida Rdd6584G(Ec) Touch Screen Control System
Cutting Speed	0-0-1, 500mm
Graphic Format Supported	Plt, Dxf, Ai, etc.
Vacuum Adsorption	8 Zones Partition Adsorption
Vacuum Pump	9.0kw, Air Cooling, Buil-in, with Silencer
Transport Package	Plywood Case
Specification	: 3690*2345*1400mm, 800kgs
Trademark	UPGOAL
Origin	Jinan City, Shandong Province, China
HS Code	8479899990
Production Capacity	200 Sets/Month

Packaging & Delivery

Package size per unit product 383.00cm * 224.00cm * 162.00cm Gross weight per unit product 1000.000kg

Product Description

High 400W CNC Oscillating Knife Cutting Machine with Creasing Wheels /Mark Pen for Polyurethane PU /Rubber/PVC Floor /EVA Foam/Carbon Box 1600*3000mm

Application

UPGOAL cnc vibration knife cutting machine is widely used in cutting paper materials, automotive interior processing industry, used in the cutting processing of car seat covers, seat cushions, steering wheel grips, leather processing industry, leather cutting and punching, household fabrics, cutting of new technology materials and other industries.

Cutting materials

Cardboard, corrugated paper, honeycomb paper, leather, glass fiber, carbon fiber, fabric, self-adhesive, film, foam board, acrylic board, rubber, gasket material, clothing cloth, footwear material, luggage material, non-woven fabric, carpet, Sponge, KT board, PU, EVA, XPE, PVC, PP, PE, PTFE, ETFE and composite materials.

Features

1. With 4 kinds of tools : oscillating knife/milling cutter/creasing wheels/ mark pen

2.The ultra-high frequency 400W vibration knife cutting technology eliminates the irregularities of manual cutting, the limitation of the accuracy of the punching machine, and the scorching odor of the laser cutting machine. High efficiency and fast speed make leather and PU cutting become artistic enjoyment.

3. With a 3.5kw air cooling milling knife tool: with high speed rotary tool, makes the cutting edge of material be smoother, in addition to processing for hard materials, can also process for foam material. Application: acrylic, wood, PVC foam sheet, PVC expansion sheet and other industries4. With Creasing wheels,rolling over the material by a circular wheel creates an indentation effect on the material,and with wheels of different specifications, different indentation effects can be achieved. Advantage: can change the wheels fast.4. With Mark pen: The system drives the pen tool to move, which can mark, write text and draw graphics on the material. Markable Materials: Most Materials.

5. Imported original PMI, Taiwan Linear square guide rail with ball bearing slide block which ensure high weight capacity, high precision, smooth and steady running. Adopt WMH brand, Herion helical gears pinion and rack transmission for X and Y axis, higher running speed and efficiency, and more durable.

6. Adopted famous RuiDa RDD6584G touch screen control system supports both USB and Ethernet connection, has a knife cutting controller with tool direction following control function. It integrates the processing of tools such as vibrating cutters, round cutters, milling cutters, and pressing wheels. It also integrates feeding, circular punching, and V-shaped special punching. Hole, pen processing, red light positioning and a series of functions.

7. Whole cast aluminum vacuum table with imported felt, ensuring the machine stablity.

and 8 zones partition adsorption, ensuring the machine stablity.8. Equipped with 9.0KW high pressure air cooling vacuum pump with silencer, built-in design, high adsorption ability.

9.China HCFA 750W servo motor driver for XYZ-axis and 400W 100W Panasonic Japan servo motor driver for DC-axis,, ensuring the processing speed & precision.

10. With dust collector, suck the dust, milling dust, keep the machine cleaning.11. With anti-collision safety switch 4 sets12. Semi-auto lubrication13. The cutting efficiency is high, the surface is smooth and flat, which greatly saves costs

14. A variety of tool heads(Vibrating knife, high-power round knife, punching knife, pneumatic knife, multi-layer knife, drag knife, half cutter, bevel cutter, milling cutter, etc. all can be installed), quick replacement to adapt to different materials

15. Convenient output, high-speed cutting, rapid prototyping, intelligent typesetting, saving materials

16. Supports multiple formats such as DXF, PLT, HPGl, etc., without cutting tools, saving manpower and material resources, and simplifying the work process.

17. Improve the cutting speed and efficiency, and provide strong support for high-speed cutting of the electric vibrating knife with a frequency of up to 25,000 times/min, up to 1000mm/s.

18. Smooth operation, fine and smooth incision, powerful function, can effectively solve various problems such as proofing.

Technical Parameters

Model	UG-1630V
Effective cutting area	1600*3000mm
Working table	Fixed aluminum adsorption vacuum working table with adsorption felt( imported)
Material fixed method	Vacuum partition suction system,8 zones
Cutting head	Three
Oscillating knife Cutting head	High 400W
Mill knife cutting head	3.5kw air cooling spindle( ER25)
Creasing wheels	With, CLT
Mark pen	With, CLT
Control system	RuiDa RDD6584G(EC) touch screen control system
Cutting software	RuiDa VcutWorks( supports WLAN cable & USB cable)
Cutting speed	0-1,500mm/s(according to different cutting materials)
Cutting thickness	≤50mm
Cutting accuracy	≤0.1mm
Drive system	China HCFA 750W servo motor driver for XYZ-axis and 400W 100W Panasonic Japan servo motor driver for DC- axis
Guide rail	Original PMI, Taiwan, linear square guide rail, diameter 20mm
Transmission system	Original Helical rack and pinion transmission(WMH brand, Herion)
Vacuum pump	Air cooling, 1set, 9.0KW, with silencer, built-in
Safety device	Anti-collision system( 4 sets)
Graphic format supported	PLT, DXF, AI, etc.
Compatible	CORELDRAW, PHOTOSHOP, AUTOCAD, TAJIMA, etc.
Voltage	AC220V ±10%,50/60Hz, single phase or AC380V ±10%,50/60Hz, three phases
Accessories	Cutting bits-10pcs, USB cables, switches-2pcs, limit sensor-1, long life(5pcs), short knife( 15pcs), belt(1pc), anti-collision sensor(1pc), etc
Certificate	CE

Reference Sample Photos

Reference Working Videos
10-20mm Rubber Plate cutting: https://youtu.be/q8a_hFSckhs
10-20mm polyurethane PU Cutting: https://youtu.be/RP7GLnEdUJ0
PVC floor cutting: https://youtu.be/DjvGKXXcmfg
EVA foam cutting: https://youtu.be/2wv9Yr2yvHE
Corrugated Carton Box cutting: https://youtu.be/7LoHhiJH_sw



Accessories & Packing & Delivery
