DESCRIPTION

Basic Info

Model NO.	DA-1180DB
Cover	Half Cover
Transport Package	Wood
Specification	2300KG
Origin	China
HS Code	8459619000
Production Capacity	About 1500 Sets/Year

Product Description

High Precision Automatic CNC Cutting Machine for Phone Glass, Acrylic, PVC, Metal, Non-Metal, Aluminum, Ceramic, Composite Material etc





Application of large precision carving machine:
Precision special-shaped edge grinding, punching, chamfering, etc for large display window panel, capacitive glass panel, resistance glass panel, touch glass panel, and various kinds of glass panel

Features:1) The machine body is made of superior "Jinan green" marble. The machine weight is up to 4500KG. The machine structure is stable and permanent without deformation; it can ensure the persistent accuracy.2) With imported screw and guide rail, NSK P4 bearing;3) Professional design of waterproof and structure of machine tools;4) Electronic control design of waterproof type;5) Numerical control system with high stability;6) Automatic lubrication system;7) The practical, fast and convenient pneumatic jigs and product positioning jigs are equipped.8) Innovative cooling design to improve tool cooling efficiency and yield.9) Humanization design of automatic alarm;

CNC Machine Specifications
1	ITEM/MODEL	DA-1180SDB	DA-1150FB
2	Processing Materials	Aluminum and copper highlights	Large size optical glass
3	WORKING TABLE
4	Table shape	T- type groove
5	Table size	1100×800mm
6	Max load capacity	200kg
7	MOVEMENT & RANGE
8	Single head processing	1100×800mm×200mm
9	Double spindle center distance	-
10	Spindle nose to worktable height	180mm
11	ACCURACY
12	Positioning accuracy	0.008/300mm
13	Repeatability accuracy	0.005mm
14	SPINDLE
15	Spindle power	0.8/1.2/2.2/3.3 Kw(Optional)
16	Spindle speed	24000/36000/60000/100000 rpm(Optional)
17	Cutters change method	Pneumatic(Or manual)
18	Cutters specification	Φ10/Φ6/Φ4/Φ3.175
19	FEEDING SPEED
20	Rapid traverse	18m/min
21	Cutting feed rate	9m/min
22	REQUIRED POWER
23	Total Power	7.5Kw
24	Machine weight	2300kg
25	Machine size	2340*1770*1520mm
26
27	Other Standard Parts
28	Water injection system	Ring water injector
29	Filter	4 pcs
30	Oil drain	Volumetric oil drain
31	Oil pump	Automatic alarm oil pump
32
33	CNC System Specifications
34	System language	Chinese/English
35	Motion Axis	Weihong /Ncstudio/Di-ao/Syntec/Qiezhi/LNC
36	Minimum moving unit	0.001mm
37	Motion Axis	4 Axes
